2 Rolls 4.02" x 1476'(102mmx450m) Wax/Resin Thermal Transfer Ribbon, Core 1", Black, Ink Outside

WISHLIST
Wax/Resin Thermal Transfer Ribbon
Quantity
ADD TO CART
BUY IT NOW
Detail

Click here to request free sample ribbon

Description:

The 4.02" x 1476' wax/resin thermal transfer ribbon is an outstanding choice for diverse labeling needs in manufacturing, logistics, and food industries. Its combination of durability and print clarity makes it ideal for producing reliable, high-quality labels that can withstand various operational challenges and regulatory requirements.
  • Basic Information: 4.02" x 1476'(102mmx450m), Core size 1", CSO (Coated Side Out), without the notch.
  • Printer Compatible: Compatible with a 1-inch core roller, Zebra Brand Industrial Printer S4M, Z4M, 105SE, 105S, 105SL, 105SLPlus, 160S, S500, S600, Z4000, ZT200, ZT220, ZT230, ZT410, ZT420, ZT610, ZM400, ZM600, 110Xi4, 140Xi4, 170Xi4, 220Xi4, RZ400, RZ600, R110Xi4 printers and Godex ZX420, ZX430, EZ2050, EZ2150, EZ2250, EZ2350, ZX1200i, ZX1300i, ZX1600i, GX4200i, GX4300i, GX4600i, TEC, INTERMEC, CITIZEN, SATO, TSC, ARGOX Thermal Printers using (CSO) INK SIDE OUT RIBBON.
  • Print Durability: Wax/Resin Ribbon combines the benefits of both wax and resin, providing excellent resistance to smudging, scratching, and fading, making it suitable for challenging environments. Delivers sharp and clear text and images, ideal for detailed graphics and high-resolution barcodes.
  • Applications:
  •     Manufacturing: Commonly used for labeling products, components, and packaging, ensuring that labels remain intact in industrial environments.
        Logistics and Distribution: Essential for generating shipping labels, barcodes, and tracking systems that endure the demands of transportation and storage.
        Food and Beverage: Effective for labeling products that require compliance with regulations and need to withstand varying temperatures and conditions.
  • Recommended Label Type: Standard and weatherproof thermal transfer labels, Coated Paper, Plain Paper, Matte Synthetic Label, Tag.
  • Suitable Label Sizes:  Accommodates labels up to 4 inches in width, making it suitable for sizes such as  4" x 6",  4" x 3",  4" x 2", and other custom formats.

Technical Specification:

4.02” x 1476' Wax/Resin Printer Ribbon

Material Wax/Resin Case Count 2 Rolls
Ribbon Width 4.02"(102mm) Core Material Paper Core
Ribbon Length 1476' (450m) Total Thickness 7.2±0.5 μm
Core Size
1" Ink Melting Point 72 ℃
Ink Side Coat side out(CSO), without notch Extra Core Without Extra Core
Ink Color Black Printing Speed
2-10 IPS
Heat Resistance
4
Scratch Resistance
4.5
Solvent Resistance
3
Label Applicability
5

Thermal Transfer Ribbon Calculate:

  • 1 roll of 4.02" x 1476' ribbon can print approximately 2,860 labels measuring 4" x 6"

  • 1 roll of 4.02" x 1476' ribbon can print approximately 5,560 labels measuring 4" x 3“

  • 1 roll of 4.02" x 1476' ribbon can print approximately 8,100 labels measuring 4" x 2"

Maintenance Tips:

  • A sealed thermal transfer ribbon can typically last between 1 to 2 years if stored under suitable conditions. It’s advisable to keep ribbons in a cool, stable area away from sunlight. Extreme temperatures should be avoided, as they may cause the ribbon to soften or become brittle, affecting the print.
